Install a 3-Node HA Kubernetes (K3s) Cluster on Ubuntu Server 24.04 Step-by-Step (Proxmox/VM Friendly)

This hands-on tutorial walks you through building a high-availability (HA) Kubernetes cluster using K3s on Ubuntu Server 24.04. We’ll use three VMs (control-plane + embedded etcd) so the control plane is fault-tolerant and production-style — perfect for homelab and career practice.

You’ll do this:

1. Create VM #1 and apply a clean Ubuntu baseline (swap off, NTP, firewall, kernel modules).
2. (Important when cloning) Regenerate machine-id so clones get unique identity.
3. Turn VM #1 into cp1 (cluster init).
4. Join cp2 and cp3 as additional control-plane nodes.
5. Verify nodes and etcd membership.

We’re using K3s because it’s upstream Kubernetes with a lighter footprint and simple HA (embedded etcd). Everything here works great on Proxmox VEs, ESXi, or any hypervisor.

Topology & IP Plan

Node	Hostname	Role	IP
VM #1	k3s-cp1	control-plane + etcd (init)	10.11.12.11
VM #2	k3s-cp2	control-plane + etcd (join)	10.11.12.12
VM #3	k3s-cp3	control-plane + etcd (join)	10.11.12.13

Adjust addresses for your LAN. Use static IPs.

0) Create VM #1 and Install Ubuntu 24.04

In your hypervisor (e.g., Proxmox), create a VM with:

• 2 vCPU (min), 4–8 GB RAM (more is nicer), 20+ GB disk
• VirtIO SCSI disk, VirtIO NIC (or default)
• Enable the QEMU Guest Agent

Install Ubuntu Server 24.04 LTS (minimal is fine). After first boot, SSH in.

1) Base OS Baseline (Do this on each control-plane VM — cp1, cp2, cp3)

Start on VM #1 now; you’ll repeat later on VM #2 and VM #3.

sudo -s

# Keep the OS fresh
apt update && apt -y full-upgrade

# Handy & needed packages
apt -y install qemu-guest-agent curl ufw htop ca-certificates gnupg
systemctl enable --now qemu-guest-agent

# Disable swap (Kubernetes requirement)
swapoff -a
sed -i '/ swap / s/^/#/' /etc/fstab
free -h   # Swap should now be 0

# Enable NTP (TLS and etcd hate clock skew)
timedatectl set-ntp true
timedatectl status

# Kernel modules K8s expects
modprobe br_netfilter overlay
tee /etc/modules-load.d/kubernetes.conf >/dev/null <<'EOF'
br_netfilter
overlay
EOF

# Netfilter settings
tee /etc/sysctl.d/99-kubernetes.conf >/dev/null <<'EOF'
net.bridge.bridge-nf-call-iptables=1
net.ipv4.ip_forward=1
EOF
sysctl --system

UFW (Firewall) — Open the right ports between the nodes

Replace CIDR with your LAN if needed.

ufw allow OpenSSH
ufw allow from 10.11.12.0/24 to any port 6443 proto tcp    # Kubernetes API
ufw allow from 10.11.12.0/24 to any port 2379:2380 proto tcp # etcd peer/client
ufw allow from 10.11.12.0/24 to any port 10250 proto tcp   # kubelet
ufw allow 8472/udp                                         # flannel VXLAN (default CNI in K3s)
ufw --force enable
ufw status

2) (Cloning Tip) Regenerate machine-id Before You Clone

If you plan to clone VM #1 to create VM #2 and VM #3, you must give each clone a unique machine ID. You can do it like this on the clone(s) before first boot, or right after boot:

# Regenerate machine-id (run as root)
systemctl stop systemd-machine-id-commit.service 2>/dev/null || true
rm -f /etc/machine-id /var/lib/dbus/machine-id
systemd-machine-id-setup
ln -sf /etc/machine-id /var/lib/dbus/machine-id
cat /etc/machine-id

That’s all you need — it prevents “duplicate node name/identity” problems later.
(If you prefer reading more, check man machine-id on Ubuntu.)

Now set each VM’s hostname and IP:

# Example on VM #1
hostnamectl set-hostname k3s-cp1
# On VM #2 use k3s-cp2, on VM #3 use k3s-cp3

# Ensure /etc/hosts has proper lines:
# (edit to reflect your network)
tee -a /etc/hosts >/dev/null <<'EOF'
10.11.12.11  k3s-cp1
10.11.12.12  k3s-cp2
10.11.12.13  k3s-cp3
EOF

Reboot if you changed hostnames/networking: reboot

3) Configure cp1 (Cluster Init)

On k3s-cp1 (10.11.12.11):

curl -sfL https://get.k3s.io | INSTALL_K3S_EXEC="server --cluster-init" sh -
systemctl status k3s --no-pager

Check node state:

k3s kubectl get nodes -o wide

You should see k3s-cp1 as Ready.

Export kubeconfig for your user (optional convenience):

mkdir -p ~/.kube
sudo cp /etc/rancher/k3s/k3s.yaml ~/.kube/config
sudo chown $USER:$USER ~/.kube/config
# Replace localhost with LAN IP so you can kubectl from your workstation if needed
sed -i 's/127\.0\.0\.1/10.11.12.11/' ~/.kube/config
kubectl get pods -A

Get the full join token (include the CA hash)

sudo cat /var/lib/rancher/k3s/server/node-token

Copy the entire string. It contains two :: separators — don’t truncate it.

4) Prepare cp2 and cp3 (Baseline + Hostname + Static IP)

Repeat Section 1 (baseline) on k3s-cp2 and k3s-cp3:

• Packages, swap off, NTP on, kernel modules/sysctl, UFW rules
• Set hostname (k3s-cp2, k3s-cp3)
• Confirm IPs (10.11.12.12, 10.11.12.13)
• If cloned from cp1, regenerate machine-id (Section 2)

Sanity checks:

hostname
ip -4 a
free -h          # swap 0
timedatectl      # NTP synchronized: yes
ping -c2 10.11.12.11
curl -k https://10.11.12.11:6443/version   # should return JSON with gitVersion

5) Join cp2 as an HA Control-Plane Node

On k3s-cp2 (10.11.12.12):

export K3S_URL="https://10.11.12.11:6443"
export K3S_TOKEN="<PASTE_FULL_TOKEN_FROM_CP1>"

curl -sfL https://get.k3s.io | \
  INSTALL_K3S_EXEC="server --server ${K3S_URL} --node-name k3s-cp2" sh -

systemctl status k3s --no-pager

Verify from cp1:

k3s kubectl get nodes -o wide

Expected: k3s-cp1 and k3s-cp2 both Ready (roles include control-plane,etcd).

6) Join cp3 as an HA Control-Plane Node

On k3s-cp3 (10.11.12.13):

export K3S_URL="https://10.11.12.11:6443"
export K3S_TOKEN="<PASTE_FULL_TOKEN_FROM_CP1>"

curl -sfL https://get.k3s.io | \
  INSTALL_K3S_EXEC="server --server ${K3S_URL} --node-name k3s-cp3" sh -

systemctl status k3s --no-pager

Verify from cp1:

k3s kubectl get nodes -o wide

Expected: all three nodes Ready with roles control-plane,etcd.

7) Deep Verification

a) Nodes

k3s kubectl get nodes -o wide

Should list:

NAME      STATUS   ROLES                       VERSION        INTERNAL-IP
k3s-cp1   Ready    control-plane,etcd,master   v1.33.x+k3s1   10.11.12.11
k3s-cp2   Ready    control-plane,etcd,master   v1.33.x+k3s1   10.11.12.12
k3s-cp3   Ready    control-plane,etcd,master   v1.33.x+k3s1   10.11.12.13

b) Etcd members (from cp1)

k3s etcdctl --write-out=table member list

You should see 3 members.

c) System pods

k3s kubectl get pods -n kube-system -o wide

All core components should be Running (coredns, local-path-provisioner, flannel, metrics-server, etc.)

8) Common Join Errors & Quick Fixes

• “not authorized” / CA not trusted
  • You probably used an incomplete token. Re-copy from cp1 and ensure it includes the :: CA hash.
• “duplicate node name found”
  • The clone kept old K3s or hostname/machine-id.
    Fix on the joining node: /usr/local/bin/k3s-uninstall.sh 2>/dev/null || true rm -rf /var/lib/rancher/k3s /etc/rancher/k3s hostnamectl set-hostname <unique-name> # (If cloned) regenerate machine-id as shown earlier Then re-join with --node-name <unique-name>.
• API not reachable
  • Open UFW ports (6443, 2379–2380, 10250, 8472/udp), test with: curl -k https://10.11.12.11:6443/version
• TLS/etcd weirdness
  • Ensure time is in sync on all nodes: timedatectl status → NTP synchronized: yes
• Swap enabled
  • Must be off on every node (free -h).

To see errors quickly:

# on the failing node
journalctl -u k3s -n 200 --no-pager

9) (Optional) Quality-of-Life Installs Next

• MetalLB → Allocate EXTERNAL-IPs on your LAN for LoadBalancer services.
• Longhorn → Simple, powerful persistent storage with Web UI.
• Kubernetes Dashboard or Rancher → Full Web UIs for your cluster.
• cert-manager + ExternalDNS → Automatic HTTPS + DNS.
• Argo CD → GitOps.
• kube-prometheus-stack → Prometheus, Alertmanager, Grafana, Node Exporter.

If you want, I can extend this post with a clean “Part 2” covering MetalLB + Longhorn + Dashboard/Rancher setup.

10) Summary

You now have a production-style HA Kubernetes control plane running K3s + embedded etcd across three Ubuntu 24.04 VMs:

• Resilient control plane (3 etcd members)
• Clean baselines (swap off, NTP, firewall, kernel modules)
• Safe cloning process (machine-id regeneration)
• Verified nodes and etcd health
